The Basics LITE
The Basics LITE by ETron Circuit Labs is Electronic Education Curriculum designed for the 21st century student. This fully interactive guide is ready to take your technology program to the next level. This fully interactive course teaches each component, how it works and interacts with other components. It progresses into more complex labs with exciting projects the stimulate learning and inspire further exploration. The Basics LITE is fully backwards compatible with Tron.ix 1 and Mr. Circuit 1 courses.
LAB 1 - Automatic Nightlight
In this Lab you will build a Automatic Night Light circuit that will get brighter at night and dimmer during the day.
LAB 2 - Electronic Metronome
In this Lab you will build an Electronic Metronome that will produce an adjustable “tic-tic” click used for keeping rhythm in music.
LAB 3 - Electronic Motorcycle
In this Lab you will build an Electronic Motorcycle circuit that will produce a sound that mimics a motorcycle speeding up and slowing down.
LAB 4 - Variable Speed Lights
In this Lab you will build a Variable Speed Lights circuit that will use a potentiometer to control the rate at which the LED will blink.
LAB 5 - Audio Generator
In this Lab you will build an Audio Generator circuit that will allow you to control the frequency of the pulses that produce the tone the speaker will put out
LAB 6 - Police Siren
In this Lab you will build a Police Siren circuit that will produce a realistic police siren sound.
LAB 7 - Screaming Box
In this Lab you will build a Screaming Box circuit that will produce a high pitched squealing sound when the photocell is exposed to light.
LAB 8 - Variable Timer
In this Lab you will build a Variable Timer circuit that will allow you to adjust the time the LED stays lit before turning off automatically.
LAB 9 - Moisture Detector
In this Lab you will build a Moisture Detector circuit that will allow the moisture level of soil as measured by a blinking LED.
LAB 10 - Morse Code Oscillator
In this Lab you will build a Morse Code Oscillator that will produce a tone pulse each time a switch is pressed.
LAB 11 - Nose Beeper
In this Lab you will build a Nose Beeper circuit that will use a human body to conduct electricity which completes the circuit creating a beeping sound.
LAB 12 - British Siren
In this Lab you will build a British Siren circuit which creates a 2 tone sound that will mimic a British police siren.
LAB 13 - Insanity Alarm
In this Lab you will build an Insanity Alarm circuit that will use a photocell as a sensor to turn on and off the alarm sound when moved from dark to light spaces.
LAB 14 - Electronic Organ
In this Lab you will build an Electronic Organ that will allow you to create the Do-Re-Mi-Fa-So-La-Ti-Do sounds by moving the probes across different resistors.
